TEMPCTRL & SIL HEAT TAPE-2FT

Description

XtremeFLEX™ BS0 Silicone Rubber Heating Tape

• Silicone rubber extruded outer sheath
• Suitable for electrical conductive surfaces
• Multi-stranded resistance wire for increased durability and flexibility
• Fiberglass knitted and braided heating element construction
• Moisture and chemical resistant
• Maximum exposure temperature: 232°C (450°F)
• Power density: 4.3w/ in.² (0.020w/mm²)
• Power leads, 24 in. (610mm) with 120VAC: Separable standard 2-prong power plug
• Single power lead on opposite ends
• Voltage: 120V

• Digital on/off temperature controller
• Compatible with wide range of heaters and applications
• Self contained, plug and play design
• Easy programming (°C or °F)
• Temperature control range: 0° to 600°C or 32° to 999°F; Accuracy: ±0.6% of span, ±1 digit
• Exposure temperature: 0° to 50°C (32° to 122°F); Humidity: 80%, noncondensing
• 10A fused output
• Built-in J type thermocouple; 5 ft. (1.5m) long
• Upper and lower limits of setpoint can be adjusted by a single key
• Hysteresis adjustable between 1 and 20 degrees
• Input power cord 5 ft. (1.5m)] for 120VAC unit: NEMA 5-15 plug
• Output power cord 5 ft. (1.5m)] for 120VAC unit: NEMA 5-15R receptacle
